 Home >> Products >> Optional Spare Parts for Combined Machine
  Mowing Wheels

Model: C300-MW60
Suit for C300 and C400 .

Description:
Wheelsystem: With the wheelsystem, you can easily move your machine.

  Spiral Cutterhead

Model: C300-CH52-4S
D.70×L.300 N.52,4 spirals,shearcut
Model: C400-CH85-5S
D.70×L.400 N.85,5 spirals,shearcut

Description:
This type of spiral cutterhead is designed with a true shear cut. The carbide knives sit at at angle along the helical grooves. It reduces the tear-out of your work, makes smaller chips and less noise than any other type of cutterheads. If one knife edge is dull or nicked, just turn it to another edge in seconds and the cutterhead works pefectly as a new one again. This greatly reduces your down time. Replace the inserts only when four edges are dull. You don't need to replace all the knives as you have to do with the conventional single straight knife. It pays you back in a very short time.

  Cutter shaft Tersa (MBM Italian )

Model: C300-TERSA

Model: C400-TERSA


Description:
The construction concept of this tool allows the automatic block of the cutters in using the centrifugal force. The exactness of the position is guaranteed on all the sharp edge and on the whole length of the planing shaft. For a correct use of the tool we recommend using the suitable products to clean the support runner of the cutters.


  Angle Ruler Pro
Model: C300-ARP850
0-45°×850

Description:
In both directions 2 x 45° mitre cross-cut fence. The length is 850mm.
Also named: Mitre cross-cut fence


  Contouring Fence
Model: C300-CF180
For C300/C400/400B

Description:

  Tenoning
Size: 326×500
For C300/C400/400B
Description:
Safety hood for tenoning with diameter capacity 260 mm.
  Wescott(Churck)
Model:Wescott
M18×1.5S (Φ1-Φ16) mm
For mortiser function

  Mortiser Bits
Model: Mortiser Bits
Description:(mm)
Shank Dia:16
Working Dia.: 6-8-10-12-14-16
L: 105-115-125-135-145-155
  Mortiser function: Three awl bits
Model: AWL
Description:(mm)
Shank Dia:6-16
Working Dia.:
Φ6*9-Left- HSS
Φ8*117-Left-HSS
Φ10*120-Left-HSS
Φ12*151-Left-HSS
Φ14*151-Left-HSS
Φ16*160-Left-HSS
  Profile Cutter Heads
Model:TS30
D.120×d.30×H.40
Model:TS35
D.120×d.35×H.40
Model:TS50
D.120×d.35×H.40
  Planer Knives
L.300
300×20×3
L.400
400×20×3
  Saw Blade
D.250
D.250×d.30×3×60T
D.250×d.30×3×40T
D.250×d.30×3×42T

D.300
D.300×d.30×72T
  Engraver Blade (Scoring Blade)
D.90
D.90×d.22×3.1×12T
